Stretch Film

Cast Stretch Film
Cast stretch film also called cast film or cast wrap, is manufactured using the cast extrusion process. Typical characteristics of cast stretch films are: excellent optics, clear, glossy, superior tear resistance, quiet unwind, consistent cling and consistent film thickness.

Blown Stretch Film
Manufactured using the blown film extrusion process and also referred to as blown film. Typical blown strecth film characteristics are: poor optics, hazy, dull, excellent puncture resistance, very noisy unwind and high force on load.

Hand Stretch film
Stretch film designed specifically to be applied manually is referred to as hand stretch film. It is also referred to as hand film, hand stretch wrap, hand wrap or manual pallet wrap. It is typically utilized in lower capacity packaging operations. However the efficiency of manual stretch wrap packaging should be regularly re-evaluated against potential benefits of upgrading to a machine wrapper. Choosing the right stretch applicator will result in more efficient and cost effective packaging operations.

Machine Stretch film
Stretch film designed to be applied with a stretch wrap machine is referred as machine stretch film. It provides many advantages over hand film including: faster and more efficient packaging, reduced packaging material costs, safer application, more secure loads and more. Common machine stretch film types: cast machine stretch film, blown machine film and prestretched films.

Hand Stretch Film

Hand Stretch film
Stretch film designed specifically to be applied manually is referred to as hand stretch film. It is also referred to as hand film, hand stretch wrap, hand wrap or manual pallet wrap.
It is typically utilized in lower capacity packaging operations. However the efficiency of manual stretch wrap packaging should be regularly re-evaluated against potential benefits of upgrading to a machine wrapper. Choosing the right stretch applicator will result in more efficient and cost effective packaging operations.

BEMIS (Handfilm-Blown)
Item Code	Width	Gauge	Ft/Rl	Lbs/Rl	Cs/Skid	Color
B1260	12"	60	4X2000	22.9	36	CLEAR
B1280	12"	80	4X1500	22.9	36	CLEAR
B1560	15"	60	4X2000	28.6	36	CLEAR
B1580	15"	80	4X1500	28.6	36	CLEAR
B1860	18"	60	4X2000	34.4	36	CLEAR
B1870C	18"	70	4X1500	29.8	36	CLEAR
B1880	18"	80	4X1500	34.4	36	CLEAR

BEMIS (Handfilm-Blown)
Item Code	Width	Gauge	Rl/Ft	Lbs/Cs	Cs/Skid	Color
B1290	12"	90	4X1500	26.8	36	PURPLE
B1590	15"	90	4X1500	33.5	36	PURPLE
B1890	18"	90	4X1500	40.2	24	PURPLE

AEP Linear Handwrap ( Blown ) 4 rolls per case
Item Code	Width	Ga.	Ft/Roll	Lbs/Cs	Cs./skid	Color
LB1260	12"	60	2000	23.2	60	CLEAR
LB1270	12"	70	1500	20.0	60	CLEAR
LB1280	12"	80	1500	23.2	48	CLEAR
LB1560	15"	60	2000	28.8	48	CLEAR
LB1570	15"	70	1500	25.2	48	CLEAR
LB1580	15"	80	1500	28.8	60	CLEAR
LB1590	15"	90	1500	32.4	60	CLEAR
LB1860	18"	60	2000	34.4	48	CLEAR
LB1870	18"	70	1500	30.4	48	CLEAR
LB1880	18"	80	1500	34.4	48	CLEAR
LB1890	18"	90	1500	38.8	48	CLEAR
LB18120	18"	120	1000	34.4	48	CLEAR

AEP Linear Handwrap ( Cast ) 4 rolls per case
Item Code	Width	Ga.	Ft/Roll	Lbs/Cs	Cs./skid	Color
LC1270	12"	70	1500	20.0	60	CLEAR
LC1280	12"	80	1500	23.2	60	CLEAR
LC1570	15"	70	1500	25.2	48	CLEAR
LC1580	15"	80	1500	28.8	48	CLEAR
LC1590	15"	90	1500	32.4	48	CLEAR
LC1870	18"	70	1500	30.4	48	CLEAR
LC1880	18"	80	1500	34.4	48	CLEAR
LC1890	18"	90	1500	38.8	48	CLEAR

AEP Linear Handwrap/ (Micron Gauges) 4 rolls per case
Item Code	Width	Micron / Ga	Ft/Roll	Lbs/Cs	Cs./skid	Color
LM1616.5	16"	16.5 / 65	1500	24.8	48	CLEAR
LM1814.5	18"	14.5 / 57	1500	24.8	48	CLEAR
LM1816.5	18"	16.5 / 65	1500	28.0	48	CLEAR

AEP Linear Prestretch 4 rolls per case
Item Code	Width	Micron / Ga	Ft/Roll	Lbs/Cs	Rolls/skid	Color
LX15B	15"	7.6 / 30	2000	3.6	126	CLEAR
LX18B	18"	7.6 / 30	2000	4.3	128	CLEAR

EQ HAND FILMS
EQUIVILENT TO .070 GUAGE
		Gauge
Item Code	Width	EQ/ACT	RL/FT	Lbs/Cs	Cs/Skid	Color
EQ1670	16"	70/51	4X1500'	19.6	36	CLEAR
EQ1870	18"	70/51	4X1500'	22	36	CLEAR
EQUIVILENT TO .080 GUAGE
		Gauge
Item Code	Width	EQ/ACT	FT/RL	Lbs/Cs	Cs/Skid	Color
EQ1680	16"	80/57	4X1500'	21.9	36	CLEAR
EQ1880	18"	80/57	4X1500'	24.6	36	CLEAR
EQUIVILENT TO .090 GUAGE
Item Code	Width	EQ/ACT	FT/RL	Lbs/Cs	Cs/Skid	Color
EQ1690	16"	90/63	4X1500'	24.2	36	CLEAR
EQ1890	18"	90/63	4X1500'	27.2	36	CLEAR


SIGMA BLOWN HAND FILMS
Item Code	Width	GUAGE	FT/RL	Lbs/Cs	Cs/Skid	Color
S1275	12"	75	4X1500'	21.6	48	CLEAR
S1280	12"	80	4X1500'	23	48	CLEAR
S1875	18"	75	4X1500'	32.4	36	CLEAR
S1880	18"	80	4X1500'	34.6	36	CLEAR

SIGMA CAST HAND FILMS
Item Code	Width	GUAGE	FT/RL	Lbs/Cs	Cs/Skid	Color
S1665	16"	65	4X1500'	25	36	CLEAR
S2080BOX	20"	80	5000'	32	40	CLEAR

Machine Rolls

AEP/Linear Machine Film Cast
Item Code	Width	Ga.	Ft/Roll	Lbs/Rl	Rolls/Skid	Color
LMC2050	20"	50	9000	36.0	40	CLEAR
LMC2060	20"	60	7500	36.0	40	CLEAR
LMC2070	20"	70	6000	33.6	40	CLEAR
LMC3070	30"	70	6000	50.4	20	CLEAR
LMC2075	20"	75	5000	30.0	40	CLEAR
LMC2080	20"	80	5500	35.2	40	CLEAR
LMC3080	30"	80	5500	52.8	20	CLEAR
LMC2090	20"	90	5000	36.0	40	CLEAR
LMC3090	30"	90	5000	54.0	20	CLEAR
LMC20115	20"	115	3500	32.2	40	CLEAR

AEP/Linear Cling No Cling Premium Machine Film
Item Code	Width	Ga.	Ft/Roll	Lbs/Rl	Rolls/Skid	Color
LCNC2055	20"	55	8000	35.2	40	CLEAR
LCNC3055	30"	55	8000	52.8	20	CLEAR
LCNC2060	20"	60	7500	36.0	40	CLEAR
LCNC3060	30"	60	7500	54.0	20	CLEAR
LCNC2065	20"	65	6500	33.8	40	CLEAR
LCNC3065	30"	65	6500	50.7	20	CLEAR
LCNC2070	20"	70	6000	33.6	40	CLEAR
LCNC3070	30"	70	6000	50.4	20	CLEAR
LCNC2075	20"	75	6000	36.0	40	CLEAR
LCNC3075	30"	75	6000	54.0	20	CLEAR
LCNC2080	20"	80	5500	35.2	40	CLEAR

AEP/XRP Machine Film
Item Code	Width	Ga.	Ft/Roll	Lbs/Rl	Rolls/Skid	Color
A2042XRP	20"	42	10000	33.6	40	CLEAR
A2047XRP	20"	47	9000	33.8	40	CLEAR

AEP/Linear Cling No Cling Premium Machine Film
Item Code	Width	Ga.	Ft/Roll	Lbs/Rl	Rolls/Skid	Color
A2051	20"	51	9000	36.7	20	CLEAR

BEMIS Cast Machine Film
Item Code	Width	Gauge	Ft/Rl	Lbs/Rl	Rls/Pal	Color
BC80206	20"	60	8,000	38.2	40	CLEAR
BC65207	20"	70	6,500	36.2	40	CLEAR
BC50208	20"	80	5,000	31.8	40	CLEAR
BC60208	20"	80	6,000	38.2	40	CLEAR
BC50209	20"	90	5,000	35.8	40	CLEAR

SIGMA (CAST) MACHINE FILMS
Item Code	Width	GUAGE	FT/RL	Lbs/Cs	RL/Skid	Color
S2060	20"	60	8000'	38.4	40	CLEAR
S2070	20"	70	6500'	36.4	40	CLEAR
S2075	20"	75	6000'	36	40	CLEAR
EQ2080	20"	80/63	5000'	25.2	40	CLEAR
S2080	20"	80	5000'	32	40	CLEAR
S2090	20"	90	5000'	36	40	CLEAR
S20115	20"	115	4000'	36.8	40	CLEAR
S20120	20"	120	4000'	38.4	40	CLEAR

SIGMA (BLOWN) MACHINE FILMS
Item Code	Width	GUAGE	FT/RL	Lbs/Cs	RL/Skid	Color
S2070BL	20"	70	6000'	33.6	40	CLEAR
S2075BL	20"	75	6000'	36	40	CLEAR
S2080BL	20"	80	5000'	32	40	CLEAR
S2080BL6	20"	80	6000'	38.4	40	CLEAR
S2090BL	20"	90	5000'	36	40	CLEAR
S20100BL	20"	100	4400'	35.2	40	CLEAR
S20120BL	20"	120	4000'	38.4	40	CLEAR

Extended Core

Item Code	Width	Gauge	RL/FT	WT/CS	Cs/Skid
T2070EXT	20"	70	4X1000	22	60
T2080EXT	20"	80	4X1000	26	60
T2090EXT	20"	90	4X1000	26	60
T2080B*	20"	80	4X1000	26	42

Bundling

Item Code	Width	Gauge	RL/FT	WT/CS	Cs/Skid
3SF	3"	80	18X1000	23	60
EQ3SF	3"	47	18X1000	23	60
3SF90	3"	90	18X650	13	60
5SF	5"	80	12X1000	19	60
EQ5SF	5"	47	12X1000	19	60
5SF90	5"	90	12X650	14	60

Colored

Product identification, inventory control or shipping carrier identification. Quiet release, cast stretch film comes off the roll smooth and easy.

Item Code	Width	GUAGE	FT/RL	WT/CS	CS/Skid	COLOR
N1880B	18"	80	4X1500'	34.6	36	BLUE
18HDR	18"	80	4X1500'	34.6	36	RED
OP1880BK	18"	80	4X1500'	34.6	36	BLACK
